Customer Specific Special Order Set

Last May I sent you some drawings for a set of Lotus twin cam pistons for your assessment. After a lot of delays I now have the new crank which is a work of art,  so I’m ready to order the pistons. I’ll attach the drawings which have the bore size at a nominal 89.0mm. It’s actually 3.504”. I’m assuming that because they are to have piston-guided rods with a small end width of .725” we’ll have to use symmetrical forgings.

So, along with the drawings these are the specs.

4 pistons identical - (no RH / LH) with rings, pins and locks Bore size 3.504”

Pin height 23.25mm

Thrust  to inlet side

2 ring, Zero-gap compression ring, radial gas porting.

Piston-guided rod, small end width .725” Pin dia  21mm. (Honda rod) Small end wall thickness 5.0mm

Round wire locks

Crown vol 16.5cc

Thermal and friction coatings.

The drawings show the valve pockets in relation to the pin centre. Please check that this works out at not less than 5.1mm for the inlet, 1.85mm for the exhaust, measured vertically from the deck height of the piston. (At the valve angle of 27º these measurements would be 5.65mm and 1.85mm respectively from the deck.)

6 Cylinder JE Custom Forged Piston Set - Dish, Flat or Dome - with or without valve pockets

ALL JE Forged Piston Sets are Supplied complete with Pins Locs and JE ProSeal Rings

Please note: ALL JE Custom Pistons take 3 weeks to make + 1 week for any coating operations

6 Cylinder JE Custom Forged Piston Set -

ALL JE Forged Piston Sets are Supplied complete with Pins Locs and JE ProSeal Rings

Please note: ALL JE Custom Pistons take 3 weeks to make + 1 week for any coating operations

All Bore, Head and Stroke Combinations of L24, L26 or L28 with different Rod length and Stroke changes.
8:1 - 12:1

ALL JE Forged Piston Sets are Supplied complete with Pins Locs and JE ProSeal Rings

Please note: ALL JE Custom Pistons take 3 weeks to make + 1 week for any coating operations

Here is the link for ordering… Shipping to be calculated after we have the exact address but I would expect it to be in the $120-$150 range to Saudi Arabia.

$159 Per Engine Set x 3
1 sets of std main bearing .
1 sets of std rod bearing.

$995     JE Piston Set 89mm 8.8:1 for 500 HP Diesel Crank and P90 head.
+ Options. See order page for options

$699     133mm Forged 4340 Con Rod Set with ARP2000 Bolts

$189     .045 Cometic 89mm Head Gasket

$239     12 x New Rocker Arm
-------------
$2281 US
+
$45 Shipping to OH 44202
-------------
$2326 US
